Rich Reach YS70W economic wheel excavator: 36.8kW engine, 0.22m³ bucket, 30km/h travel speed. Reliable, low maintenance, ideal for construction & farming.
The Rich Reach YS70W is an economical 6-ton wheel excavator designed for high ROI without compromising structural strength. Powered by a Yunnei Stage IV engine (36.8kW/2200rpm) and a reliable gear pump hydraulic system, this machine delivers exceptional fuel efficiency, low maintenance costs, and long-term durability. Ideal for construction, farming, landscaping, and municipal projects.
Compared to competitors, the YS70W offers a reinforced frame, spacious cabin with excellent visibility, and a proven drivetrain that withstands tough working conditions. With a travel speed of up to 30km/h and a gradeability of 59% (30°), it moves quickly between job sites while maintaining powerful digging performance.
| Working Range | Dimensions & Weight | ||
|---|---|---|---|
| Max. digging reach | 6129 mm | Overall width | 2050 mm |
| Max. digging depth | 3115 mm | Overall height | 2876 mm |
| Max. digging height | 6454 mm | Wheel base | 2400 mm |
| Max. dumping height | 4762 mm | Overall length (transport) | 5785 mm |
| Min. tail swing radius | 1810 mm | Min. ground clearance | 220 mm |
| Engine & Performance | Capacity & Fluids | ||
|---|---|---|---|
| Rated power | 36.8 kW / 2200 rpm | Bucket capacity | 0.22 m³ |
| Operating weight | 6000 kg | Fuel tank capacity | 135 L |
| Max. digging force | 42 kN | Hydraulic tank capacity | 120 L |
| Travel speed | 30 km/h | Hydraulic working pressure | 21 MPa |
| Platform swing speed | 10.5 rpm | Rated load | 450 kg |
| Gradeability | 59% (30°) | Max. traction force | 55 kN |
* Optional dozer blade available: height 490mm, rising/lowering distance 414/100mm.
Same structural strength as 7.5-ton models but with optimized configuration – the gear pump hydraulic system significantly reduces future failure rates and lowers operating costs.
Yunnei 36.8kW diesel engine meets China IV emission standards, delivering high torque, excellent fuel efficiency, and quiet operation.
Reinforced drivetrain components ensure long service life and reliable performance even on rough terrain.
Large-size cab with well-organized button layout, outstanding all-round visibility and reduced blind spots for operator comfort and safety.
At Rich Reach, we stand behind every machine. When you purchase the YS70W wheel excavator, you receive:
We also offer free pre-delivery inspection and shipment coordination to any global port.
Standard lead time is 15-25 working days after deposit confirmation. Stock machines may be available within 7 days.
Yes, the dozer blade is an optional attachment. Please specify when ordering, and we will install it before shipment.
The YS70W uses a China Stage IV engine (equivalent to EU Stage V in terms of PM/NOx control for this power range). For regions with specific requirements, please contact our sales team for customization options.
We recommend ISO VG 46 anti-wear hydraulic oil and standard diesel (sulfur content ≤10ppm for Stage IV engines). The hydraulic tank capacity is 120L, fuel tank 135L.
We have a dedicated spare parts warehouse in Hefei. You can order via email or WhatsApp, and we will ship via DHL/FedEx or sea freight.
The YS70W can reach up to 30 km/h, making it ideal for rapid relocation between job sites.
We sincerely invite you to tour the Rich Reach manufacturing and assembly base in Hefei, Anhui Province. See firsthand our quality control processes, test the YS70W on our proving ground, and discuss tailored solutions with our engineers. Complimentary airport pickup and factory visit coordination can be arranged.
